Philips
model BX485V
Back to BX485V main page
General
features
|
Circuit type |
Superheterodyne, 452kHz IF with
delayed AVC |
|
Dimensions |
450x335x240mm, 12kg |
|
Cabinet |
Bakelite, cloth grille behind
plastic dial. |
|
Loudspeaker |
200mm, moving coil, permanent
magnet |
|
Main controls |
DC on-of, illumination on-off,
tone, volume, tuning, waveband switch |
|
Connections |
Antenna, ground, PU, external
loudspeaker |
|
Power |
6V DC |
Wave
bands
|
LW |
715-2000m |
|
MW |
185-580m |
|
SW |
49-150m |
|
SW |
32-50.5m |
|
SW |
21-32m |
|
SW |
16.5-26m |
|
SW |
11-17.5m |
Circuits
and Tubes
|
Oscillator and mixer |
ECH21 triode-heptode |
|
IF amplifier and AVC |
EAF42 diode- remote cutoff pentode
|
|
Audio amplifier and detector |
EAF42 diode- remote cutoff pentode
|
|
Audio power amplifier |
EL42 5W economy pentode |
|
Rectifier |
Synchronous chopper |
