Philips
model 362A
General
features
|
Radio type |
Mains powered table radio |
|
Circuit type |
Superheterodyne, 475kHz IF with
delayed AVC |
|
Dimensions |
600x420x325mm, 25kg |
|
Cabinet |
Veneered wood, metal ornament,
cloth grille, tilting printed glass dial in Bakelite holder |
|
Loudspeaker |
250mm, moving coil, permanent
magnet |
|
Main controls |
Volume, tone,
power/sensitivity/bandwith/PU switch, waveband switch, tuning. |
|
Extra controls |
loudspeaker on/off on some
versions |
|
Connections |
Antenna, ground, PU, external
loudspeaker |
|
Power |
AC, 110-245V in 6 steps, 90W |
Wave
bands
|
MW |
195-580m |
|
SW4 |
70-210m |
|
SW3 |
25-73m |
|
SW2 |
9.5-27m |
|
SW1(VHF) |
5-11m |
Circuits
and Tubes
|
RF preamplifier |
EF8 low noise remote cutoff
pentode |
|
Mixer |
EH2 heptode |
|
Oscillator |
EBC3 duodiode-triode |
|
IF amplifier |
EF5 remote cutoff pentode |
|
Detector and audio amplifier |
EBC3 duodiode-triode |
|
AVC and 2nd audio amplifier |
EBC3 duodiode-triode |
|
Audio power amplifier |
2x EL3 9W pentodes in parallel |
|
Rectifier |
1561 dual diode |
|
Tuning indicator |
EM1 fluorescent tube-triode |
