Philips
model 361A
General
features
|
Radio type |
Mains powered table radio |
|
Circuit type |
Superheterodyne, 475kHz IF with
delayed AVC |
|
Dimensions |
535 x 260 x 360mm, 18 kg |
|
Cabinet |
Veneered wood, cloth grille,
tilting printed glass dial in Bakelite holder |
|
Loudspeaker |
type 9614 or 9644, 200mm, moving
coil, permanent magnet |
|
Main controls |
Volume / power, tone, sensitivity,
waveband / PU switch, tuning. |
|
Connections |
Antenna, ground, PU, external
loudspeaker |
|
Power |
AC, 110-245V in 6 steps, 60W |
Wave
bands
|
MW |
170-570m |
|
SW3 |
48-170m |
|
SW2 |
16.5-48m |
|
SW1 |
9.5-16.5m |
Circuits and Tubes
|
RF preamplifier |
EF8 low noise remote cutoff
pentode |
|
Oscillating converter |
EK2 octode |
|
IF amplifier |
EF5 remote cutoff pentode |
|
Detector, AVC and audio amplifier |
EBC3 duodiode-triode |
|
Audio power amplifier |
EL3 9W pentode |
|
Rectifier |
AZ1 directly heated dual diode |
|
Tuning indicator |
EM1 fluorescent tube-triode |
